New record-breaking thermoelectric material
Eco-friendly power generation from waste heat
Peer-Reviewed PublicationIMAGE: ▲ COLLEGE OF ENGINEERING AT SEOUL NATIONAL UNIVERSITY ANNOUNCED THAT PROFESSOR IN CHUNG'S GROUP IN THE SCHOOL OF CHEMICAL AND BIOLOGICAL ENGINEERING DEVELOPED A NEW THERMOELECTRIC MATERIAL OUTPERFORMING ANY OTHER BULK MATERIAL SYSTEMS. PROVIDED BY COLLEGE OF ENGINEERING AT SEOUL NATIONAL UNIVERSITY. view more
CREDIT: SEOUL NATIONAL UNIVERSITY
◦ Prof. In Chung’s group at Seoul National University announced the development of the new record-breaking thermoelectric material consisting of less-toxic and inexpensive elements on Aug. 3 (Tue).
◦ Greater than 65% of the produced energy worldwide is lost as waste heat. Electric energy is mostly generated from fossil fuels. Accordingly, recovering such a huge amount of ubiquitous energy loss into usable forms of energy can contribute to solving energy and environmental crisis that humanity faces.
◦ Thermoelectric technology can contribute to solving such problems simultaneously. It converts heat to electric energy directly without releasing any environmentally undesirable chemical residues like greenhouse gases. However, current high-performance thermoelectric materials typically contain toxic lead and/or rare tellurium element, and their power generation efficiencies are low, making it difficult commercialize this technology.
◦ Prof. Chung’s group solved all these problems by developing a new ultrahigh performance polycrystalline thermoelectric material consisting of tin and selenium elements. Tin selenide-based material has attracted explosive academic attentions in 2014 because of the strikingly high thermoelectric figure of merit (ZT) of 2.6 reported in its single crystal form. However, the reproducibility of such high performance has been controversial so far. Futhermore, the corresponding polycrystalline materials have performed much poorer. Indeed, single crystal forms are unsuitable to mass production and commercial applications due to the high cost, lengthy and labor-intensitve production and mechanical brittleness.
◦ Prof. Chung’s group revealed the origin of poor performance of polycrystalline tin selenide materials, and developed a new synthesis process to solve all problems. As a result, the obtained new polycrystalline material exhibits thermoelectric figure of merit greater than 3.1 in a bulk form for the first time in history. Its record-breaking thermoelectric power generation efficiency exceeds 20%.
◦ Prof. Chung emphasized that “our new material open an era of the commercialization of ultrahigh performance practical thermoelectrics” like perovskite materials changing the paradigm of solar cell researches. Prof. Chung had also developed all-solid-state solar cells based on perovskite materials for the first time in 2012.
◦ This research result was published in the latest online edition (Aug. 3) of ‘Nature Materials’. This work was supported by Nano Material Technology Development and Mid-Career Research Programs throught the National Research Foundation of Korea grant funded by the Korean Government.
CAPTION
▲ Schematic illustration of thermoelectric power generation using wasted heat, and record-breaking thermoelectric performances of a new material developed by Professor Chung’s group. Provided by College of Engineering at Seoul National Universit y.
CREDIT
Seoul National University
JOURNAL
Nature Materials
ARTICLE TITLE
Breaking thermoelectric performance limits
ARTICLE PUBLICATION DATE
1-Aug-2021
Extraordinary New Material Converts Waste Heat Into Energy
Purified tin selenide has extraordinarily high thermoelectric performance.
Perseverance, NASA’s 2020 Mars rover, is powered by something very desirable here on Earth: a thermoelectric device, which converts heat to useful electricity.
On Mars, the heat source is the radioactive decay of plutonium, and the device’s conversion efficiency is 4-5%. That’s good enough to power Perseverance and its operations but not quite good enough for applications on Earth.
A team of scientists from Northwestern University and Seoul National University in Korea now has demonstrated a high-performing thermoelectric material in a practical form that can be used in device development. The material — purified tin selenide in polycrystalline form — outperforms the single-crystal form in converting heat to electricity, making it the most efficient thermoelectric system on record. The researchers were able to achieve the high conversion rate after identifying and removing an oxidation problem that had degraded performance in earlier studies.
The polycrystalline tin selenide could be developed for use in solid-state thermoelectric devices in a variety of industries, with potentially enormous energy savings. A key application target is capturing industrial waste heat — such as from power plants, the automobile industry and glass- and brick-making factories — and converting it to electricity. More than 65% of the energy produced globally from fossil fuels is lost as waste heat.
Purified tin selenide shown in pellet form. The material has extraordinarily high thermoelectric performance. Credit: Northwestern University
“Thermoelectric devices are in use, but only in niche applications, such as in the Mars rover,” said Northwestern’s Mercouri Kanatzidis, a chemist who specializes in the design of new materials. “These devices have not caught on like solar cells, and there are significant challenges to making good ones. We are focusing on developing a material that would be low cost and high performance and propel thermoelectric devices into more widespread application.”
Kanatzidis, the Charles E. and Emma H. Morrison Professor of Chemistry in the Weinberg College of Arts and Sciences, is a co-corresponding author of the study. He has a joint appointment with Argonne National Laboratory.
Details of the thermoelectric material and its record-high performance were published on August 2, 2021, in the journal Nature Materials.
In Chung of Seoul National University is the paper’s other co-corresponding author. Vinayak Dravid, the Abraham Harris Professor of Materials Science and Engineering at Northwestern’s McCormick School of Engineering, is one of the study’s senior authors. Dravid is a long-time collaborator of Kanatzidis’.
Thermoelectric devices are already well defined, says Kanatzidis, but what makes them work well or not is the thermoelectric material inside. One side of the device is hot and the other side cold. The thermoelectric material lies in the middle. Heat flows through the material, and some of the heat is converted to electricity, which leaves the device via wires.
The material needs to have extremely low thermal conductivity while still retaining good electrical conductivity to be efficient at waste heat conversion. And because the heat source could be as high as 400-500 degrees Celsius, the material needs to be stable at very high temperatures. These challenges and others make thermoelectric devices more difficult to produce than solar cells.
‘Something diabolical was happening’
In 2014, Kanatzidis and his team reported the discovery of a surprising material that was the best in the world at converting waste heat to useful electricity: the crystal form of the chemical compound tin selenide. While an important discovery, the single-crystal form is impractical for mass production because of its fragility and tendency to flake.
Tin selenide in polycrystalline form, which is stronger and can be cut and shaped for applications, was needed, so the researchers turned to studying the material in that form. In an unpleasant surprise, they found the material’s thermal conductivity was high, not the desirable low level found in the single-crystal form.
“We realized something diabolical was happening,” Kanatzidis said. “The expectation was that tin selenide in polycrystalline form would not have high thermal conductivity, but it did. We had a problem.”
Upon closer examination, the researchers discovered a skin of oxidized tin on the material. Heat flowed through the conductive skin, increasing the thermal conductivity, which is undesirable in a thermoelectric device.
A solution is found, opening doors
After learning that the oxidation came from both the process itself and the starting materials, the Korean team found a way to remove the oxygen. The researchers then could produce tin selenide pellets with no oxygen, which they then tested.
The true thermal conductivity of the polycrystalline form was measured and found to be lower, as originally expected. Its performance as a thermoelectric device, converting heat to electricity, exceeded that of the single crystal form, making it the most efficient on record.
The efficiency of waste heat conversion in thermoelectrics is reflected by its “figure of merit,” a number called ZT. The higher the number, the better the conversion rate. The ZT of single-crystal tin selenide earlier was found to be approximately 2.2 to 2.6 at 913 Kelvin. In this new study, the researchers found the purified tin selenide in polycrystalline form had a ZT of approximately 3.1 at 783 Kelvin. Its thermal conductivity was ultralow, lower than the single-crystals.
“This opens the door for new devices to be built from polycrystalline tin selenide pellets and their applications explored,” Kanatzidis said.
Northwestern owns the intellectual property for the tin selenide material. Potential areas of application for the thermoelectric material include the automobile industry (a significant amount of gasoline’s potential energy goes out of a vehicle’s tailpipe), heavy manufacturing industries (such as glass and brick making, refineries, coal- and gas-fired power plants) and places where large combustion engines operate continuously (such as in large ships and tankers).
Reference: “Polycrystalline SnSe with a thermoelectric figure of merit greater than the single crystal” by Chongjian Zhou, Yong Kyu Lee, Yuan Yu, Sejin Byun, Zhong-Zhen Luo, Hyungseok Lee, Bangzhi Ge, Yea-Lee Lee, Xinqi Chen, Ji Yeong Lee, Oana Cojocaru-Mirédin, Hyunju Chang, Jino Im, Sung-Pyo Cho, Matthias Wuttig, Vinayak P. Dravid, Mercouri G. Kanatzidis and In Chung, 2 August 2021, Nature Materials.
DOI: 10.1038/s41563-021-01064-6
The research was supported by the National Research Foundation of Korea (NRF) grant funded by the Korean government (NRF-2020R1A2C2011111), Nano·Material Technology Development Program through the NRF grant funded by the Korean Government (NRF-2017M3A7B4049274 and NRF-2017M3A7B4049273) and the Institute for Basic Science (IBS-R009-G2).
