Paving new paths for sustainable construction
IMAGE:
FORMATION OF CARBONATE MINERALS IN THE PORES AND BULK MATRIX OF THE DEVELOPED 3D PRINTABLE MATERIAL DURING CARBON SEQUESTRATION. THE CRYSTALS ARE 3-5 MICROMETERS IN SIZE AND THUS DENSIFY THE MATERIAL MATRIX.
view moreCREDIT: THE MATERIAL GROUP, CST, IISC
The construction sector today faces several challenges. Natural sand is fast becoming a scarce resource – we might run out of it by 2050. Carbon dioxide emissions, especially from manufacturing cement or fired clay bricks, are increasing every year. The amount of construction and demolition (C&D) waste is on the rise – about 150 million tonnes are generated annually in India and the recycling rate is only about 1%.
To address such challenges, researchers at the Centre for Sustainable Technologies (CST), Indian Institute of Science (IISc), are exploring ways to store carbon dioxide from industrial flue gas in excavated soil and C&D waste. These materials can then be used to partially replace natural sand. This would not only reduce the environmental impact of construction materials but also impart properties that can enhance their use for construction.
“CO2 utilisation and sequestration can be a scalable and feasible technology for manufacturing low-carbon prefabricated building products, while being aligned with the nation’s decarbonisation targets,” explains Souradeep Gupta, Assistant Professor at CST, whose lab is carrying out these studies.
Gupta’s team has shown that replacing natural sand with carbon dioxide-treated C&D waste in mortar and then curing it in a controlled, CO2-rich environment can speed up the development of the material’s engineering properties, and enhance its compressive strength by 20-22%. His lab has also tested the effect of injecting carbon dioxide gas into clayey soil – typically excavated from construction sites. This resulted in better stabilisation of clay by cement and lime, and reduced the surface area, pore volume and lime reactivity of clay in soil, thereby improving the bulk engineering performance of the material.
In a more recent study, Gupta’s team checked to see what happens when carbon dioxide is sequestered in excavated soil to develop cement-lime-soil materials, which are then used to replace up to 25% and 50% of fine aggregates by mass in mortar. “When you sequester carbon dioxide in cement-soil materials, tiny crystals of calcium carbonates are formed, which reduce the fraction of medium capillary pores, densify the interfacial zones and thus improve the compressive strength,” explains Ashutosh Dwivedi, first author and PhD student at CST. Exposing the cement-lime-soil block to carbon dioxide increased their early-age strength by about 30%, the team found. Gupta explains that carbon dioxide exposure after preparation also cuts down their curing time – the time they require to harden before being used in construction.
The team has also developed 3D-printable materials made of excavated soil stabilised with a combination of binders like Portland cement, blast furnace slag (a granular calcium-silicate byproduct) and fly ash. They found that the non-expansive clay in the excavated soil acts as an excellent thickening agent (rheological modifier) and causes the material to display superior extrusion and buildability when compared to conventional cement-sand mortars. Using these materials could also reduce the amount of cement and natural sand needed in mortar by 30% and 50% respectively, they found.
Moving forward, the team plans to examine the effect of industrial and simulated flue gas – which contains a combination of gases like carbon dioxide, sulphur dioxide, nitrogen oxide and others – on the micro and macro properties of these newly formulated materials. This would help them understand whether gases other than carbon dioxide released by industries affect the materials’ carbon-capturing potential and engineering properties.
The team is in talks with a couple of major construction companies to apply these findings to their manufacturing plants. Gupta is also part of a national committee currently working on revising the standards for natural and recycled aggregates in cement-based construction materials.
“The climate change impacts of construction materials, exacerbated by increasing CO2 emissions and sand scarcity, are increasing every year,” he says. “Finding alternatives to natural sand is the need of the hour.”
JOURNAL
Science of The Total Environment
METHOD OF RESEARCH
Experimental study
ARTICLE TITLE
Development of 3D printable stabilized earth-based construction materials using excavated soil: Evaluation of fresh and hardened properties
